nmn 5 - Laminates - fi 14030

Custom blanks from nmn 5 - laminates - fi 14030

Structure:

Flexiso® nmn 5 fi 14030 is a flexible three-layer material consisting of a polyester film laminated on both sides with calendered aramid paper of thickness 50 µm. Flexiso® nmn 5 fi 14030 is used for applications up to and including 155°C.

Property:

Flexiso® nmn 5 fi 14030 is a sheet insulation material with particularly good mechanical properties, such as tensile strength and edge tear resistance combined with high dielectric strength. Flexiso® nmn 5 fi 14030 has a smooth surface and can therefore be processed well in fully automated production lines.

Application:

Flexiso® nmn 5 fi 14030 is mainly used in electric motors as slot insulation and deck slider, as well as phase insulation. In transformer construction, Flexiso® nmn 5 fi 14030 is processed as core, layer and cover insulation.

Other forms of delivery:

We also supply stamped parts made of Flexiso® nmn 5 fi 14030 as well as moulded parts made of Flexiso® nmn 5 fi 14030. If the desired dimension is not included, please write us a message.

Storage conditions:

Flexiso® nmn 5 fi 14030 can be stored indefinitely under normal conditions (20°C, 50% RH). The material should be protected from moisture, dryness and direct sunlight and UV radiation as well as any exposure to heat.

Trademark information:

Flexiso® is a registered trademark of Dr. Dietrich Müller GmbH, Germany. Nomex® is a registered trademark of the company DuPont.
