nmn 8 - Laminates - fi 14040

Individual cuts from nmn 8 - Laminates - fi 14040

Structure:

flexiso® nmn 8 fi 14040 is a flexible three-layer material consisting of a polyester film laminated on both sides with calendered aramid paper of thickness 80 µm. flexiso® nmn 8 fi 14040 is used for applications up to and including 155°C.

Property:

flexiso® nmn 8 fi 14040 is an area insulating material of thermal class f (155°C) with particularly good mechanical properties, such as tensile strength and edge tear resistance combined with high dielectric strength. In addition, it has a smooth surface and can therefore also be processed well in fully automated production lines.

Application:

flexiso® nmn 8 fi 14040 is mainly used in electric motor construction as slot insulation and cover slides, as well as phase insulation. Also, flexiso® nmn 8 fi 14040 is used in transformer construction as core, layer and cover insulation.

Other forms of delivery:

We also supply stamped parts made of flexiso® nmn 8 fi 14040 as well as moulded parts made of flexiso® nmn 8 fi 14040. If the desired dimension is not included, please write us a message.

Storage conditions:

flexiso® nmn 8 fi 14040 can be stored indefinitely under normal conditions (20°C, 50% r. f.).

Trademark information:

flexiso® is a registered trademark of firma Dr. Dietrich Müller GmbH, Germany.
