Slot closure made of nmn 5 fi 14030 - 0.360 mm thick, 1000 x 12 x 3.0 mm

Artikel-Nr.: 00360-70130-012-030

flexiso nmn 5 fi 14030 is a flexible, three-ply material, consisting of a layer of polyester foil
laminated on both sides with satin aramid paper of 0.05 mm thickness.

flexiso nmn 5 fi 14030 is a class f (155°C) insulation material with particularly good mechanical properties such as tensile strength and edge tear resistance combined with high dielectric strength. flexiso nmn 5 fi 14030 has a smooth surface and can therefore be processed in fully automated production lines
fully automated production lines.

Coverslips made of nmn 5 fi 14030 - 0.360 mm thick1000 x 12 x 3.0 mm are used in electrical engineering to close the groove.
It is possible to reinforce the Slot closures with adhesive tape.
Care must be taken to use an adhesive tape corresponding to the insulation class.

Slot closures made of nmn 5 fi 14030 - 0.360 mm thick, 1000 x 12 x 3.0 mm are used in applications of insulation class f (155°C).
